Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75
The AirTAC Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75 is a genuine double acting, adjustable stroke ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 1000mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.
- BoreØ125 mm
- Stroke1000 mm
- Port sizeG1/2
- Acting typeDouble acting, adjustable stroke
- Rod threadM27×2.0
- CushionAdjustable, 40 mm
About the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75
Generating 6136 N of push force at 0.5 MPa, this ISO 15552 tie-rod cylinder brings four steel rods and an aluminum barrel to heavy-duty actuation. The G1/2 port feeds a 32 mm rod, yielding a safe working load of roughly 3682 N or about 313 kg lifted vertically with a 2:1 margin.
The external adjuster shortens the extend stroke on-site by up to 75 mm, giving a usable range of 925 to 1000 mm without changing the cylinder. The retract end remains fixed. A two-way piston seal and adjustable 40 mm air cushions manage deceleration, while the Viton H option extends service to 150 C.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75 Technical Specifications
| Model | Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75 |
|---|---|
| Series | SGC ISO 15552 tie-rod cylinder |
| Bore size | Ø125 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | G1/2 |
| Rod thread | M27×2.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max standard stroke | Up to 1500 mm |
Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75
| SGCJ | ISO 15552 tie-rod cylinder (adjustable-stroke type). |
|---|---|
| 125 | Bore size in mm (125 / 160 / 200 / 250). |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75 Is Used
Transfer Line Diverter
Fine-tune the 925 to 1000 mm extend reach on-site to push heavy pallets onto a bypass lane without swapping the actuator.
Stacker Height Calibration
Dial in the exact upper stop position for tier stacking, using the 75 mm external window to adapt to varying pallet heights.
Press End-Position Trim
Adjust the extend end point on the shop floor to set precise forming depth, avoiding mechanical hard-stops on the machinery.
Is the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75 the Right Cylinder?
Size this 125 mm bore against the 160 mm option if you need up to 10053 N at 0.5 MPa, or drop to smaller bores for lighter loads. The 75 mm adjust window lets you fine-tune the extend end position on-site, ideal for sharing one spare across multiple stroke variants. Mounting options include FA, LB, TC, FTC, TCM1 and TCM2. Because this is a non-magnet SKU, it cannot take CMSG or DMSG sensors. For the 1000 mm stroke, use an external guide to prevent rod bending and side-load damage.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Long-stroke side load — support the rod end
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load; support long strokes at the rod end.
- check Set cushions to minimum, then release gradually.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75 FAQ
It delivers 6136 N push and 5734 N pull at 0.5 MPa, or 8590 N push and 8028 N pull at 0.7 MPa. The theoretical max is 1251 kgf at 1.0 MPa. The air port is G1/2.
An external stop screw shortens the extend stroke by up to 75 mm on-site, giving a usable extend range of 925 to 1000 mm. The nominal 1000 mm is the maximum, and the retract end is fixed. This stop only sets position and does not lock the load.
