Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X1000-75S
2. SG series features dual Y-type unidirectional piston seals with compensation function, delivering extended service life and low starting pressure. SGC series employs custom bidirectional seal configuration with compact dimensions and built-in oil retention capability;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series adopts aluminum tube design with optional inductive magnetic ring (not available for SG series);
5. Precision adjustable cushioning for smooth stroke termination;
6. Multiple configurations and mounting accessories available for flexible system integration;
7. High-temperature resistant sealing materials support 0-150°C operating range.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ125~160 Adjustable Cylinder
AirTAC SGCJ125X1000-75S Adjustable Cylinder Specifications
- Full model: SGCJ125X1000-75S
- Series: SGCJ125~160 adjustable stroke type
- Bore size: 125mm
- Stroke: 1000mm (adjustable range: 25-1000mm)
- Rod diameter: 35mm (chrome-plated)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting type: FC3 front flange with mounting holes
- Port size: G3/8 (NPT1/4 optional)
- Temperature range: -20℃ to 80℃
- Seal material: Polyurethane (NBR available on request)
- Weight: 18.5kg (without rod end accessories)
- Dimensions:
- Body length: 1220mm (minimum retracted length)
- Stroke extension: +1000mm (max extended length 2220mm)
- Width: 155mm (flange to flange)
- Height: 165mm (including mounting base)
- Rod rotation prevention: Built-in anti-rotation guide
- Position detection: Optional magnetic piston with sensor slots
Heavy-duty adjustable stroke cylinder with precision stroke adjustment mechanism (75S suffix indicates external screw-type stroke limiter). Features double-acting operation, corrosion-resistant anodized aluminum body, and integrated shock absorption. The 75S variant includes a locknut-equipped external stopper for secure position fixing. Requires air lubrication for optimal seal performance.
- Variable height positioning in automotive assembly jigs
- Paper roll clamping systems with adjustable pressure
- Plastic injection molding machine ejectors
- Large-format CNC router tool changers
- Agricultural equipment height adjustment mechanisms
Maintenance note:
Lubricate the stopper threads monthly with ISO VG32 hydraulic oil.
Avoid lateral loads exceeding 200N. For vertical mounting,
always use rod-end support brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | SGCJ125X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
