Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X100-100
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X100-100 Adjustable Cylinder Specifications
- Series: SGCJ200~250 (Standard Type Adjustable Cushion)
- Model Code: SGCJ200X100-100
- Bore Size: Ø200 mm
- Stroke: 100 mm (standard) + 100 mm (adjustable extension)
- Operating Pressure: 0.1~1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: External adjustable (both ends)
- Mounting Style: MF1 (Standard square base with front flange)
- Port Size: G1/2 (BSPP thread)
- Piston Material: High-grade aluminum alloy (hard anodized)
- Rod Material: Chrome-plated carbon steel (S45C)
- Seal Type: NBR wear-resistant seals
- Weight: 22.5 kg (with standard accessories)
- Dimensions:
- Total Length (retracted): 350 mm
- Body Diameter: 200 mm
- Mounting Base: 250×250 mm
- Rod End Thread: M30×1.5
Heavy-duty industrial cylinder with precision adjustable cushioning mechanism, featuring dual-side shock absorption adjustment screws for optimal motion control. The triple-lip rod seal design ensures exceptional leakage prevention in high-cycle applications. Includes built-in magnet for position sensing compatibility.
- Press machine ejection systems
- Automotive welding fixture positioning
- Foundry equipment mold clamping
- Heavy conveyor gate actuators
- Industrial lifting platforms
Installation guidelines:
Maintain 0.5mm minimum alignment tolerance during mounting. Lubricate through air port with ISO VG32 turbine oil before initial use.
For vertical mounting, install lock nut (optional accessory AN20) to prevent piston rod rotation.
| Property | Property Value |
|---|---|
| sku | SGCJ200X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
