Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X100-100S
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X100-100S Adjustable Cylinder Specifications
- Series: SGCJ200~250 Adjustable Stroke Series
- Model: SGCJ200X100-100S
- Bore size: Ø200 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05~1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Port size: G1-1/2 (ISO standard)
- Piston material: High-strength aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo steel base)
- Seal type: NBR + PU composite seals
- Mounting type: 100S (basic fixed type with front/rear flange)
- Weight: ~24.5 kg (without accessories)
- Dimensions: 400mm(L) × 250mm(W) × 250mm(H) (extended length)
- Rod end thread: M45×2 (standard)
- Protection class: IP54 (standard), IP67 optional
- Max thrust: 31,400N at 0.7MPa
Heavy-duty adjustable stroke cylinder with precision position locking mechanism, featuring dual-axis adjustable stoppers for ±5mm fine-tuning. The corrosion-resistant design incorporates dust wipers and grease reservoirs, supporting high moment load applications. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Press machine stroke adjustment systems
- Automotive welding fixture positioning
- Steel coil handling equipment
- Injection molding machine ejector mechanisms
- Shipbuilding alignment jigs
Installation note:
Maintain parallel alignment within 0.2mm/m tolerance during mounting.
Requires weekly lubrication via integrated grease nipples (20g/week recommended).
Avoid side load exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | SGCJ200X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
