Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X100-10S
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X100-10S Adjustable Cylinder Specifications
- Series: SGCJ200~250 Adjustable Stroke Series
- Model: SGCJ200X100-10S
- Bore size: 200mm (ISO standard)
- Stroke: 100mm (Adjustable range: 50-150mm)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Air cushion adjustable with rubber bumper
- Port size: G1/2 (NPT1/2 optional)
- Piston speed: 50-750mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting type: Basic type (MF1) with front flange
- Rod end: Female thread M30×2.0
- Material: Aluminum alloy barrel, chromium-plated piston rod
- Seal type: NBR seals with wear-resistant ring
- Weight: 18.5kg ±2% (without accessories)
- Dimensions:
- Extended length: 575mm
- Retracted length: 475mm
- Body diameter: 230mm
- Mounting base: 250×250mm
Heavy-duty adjustable stroke cylinder featuring precision position control through mechanical stopper adjustment. The dual air cushion design minimizes impact noise while maintaining positioning accuracy within ±0.5mm. Corrosion-resistant construction with IP54 protection makes it suitable for harsh environments. Requires ISO 8573-1:2010 Class 3 lubricated air.
- Press machine height adjustment systems
- Automotive welding fixture positioning
- Foundry equipment mold clamping
- Heavy conveyor gate control
- Plastic injection molding ejectors
Installation guidelines:
Always lock adjustment bolts with 25N·m torque after positioning.
Maintain 0.5mm minimum clearance between stopper plates during adjustment.
Lubricate sliding surfaces with ISO VG32 hydraulic oil monthly.
| Property | Property Value |
|---|---|
| sku | SGCJ200X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
