Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X100-20
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X100-20 Adjustable Cylinder Specifications
- Model Series: SGCJ200~250
- Specific Model: SGCJ200X100-20
- Type: Double-acting adjustable stroke cylinder
- Bore size: 200mm (ISO 15552 standard)
- Stroke: 100mm (mechanically adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Foot-mounted (MF1 type, ISO 15552)
- Port size: G3/8 (ISO 1179-1 standard)
- Temperature range: -20℃ to 80℃
- Seal material: NBR + PU combination
- Weight: 19.8kg ±2% (excluding accessories)
- Dimensions (L×W×H):
- Basic length: 300mm
- Stroke extension: +100mm
- Body width: 220mm
- Mounting foot height: 50mm
- Rod end thread: M20×1.5
Heavy-duty adjustable stroke cylinder with precision position locking mechanism. Features dual chrome-plated piston rod (hardness HV700-850) and anti-rotation guide for high moment resistance. Integrated magnet slot for position sensing compatibility. Designed for applications requiring variable stroke control without disassembly.
- Press machine stroke adjustment systems
- Automated foundry equipment positioning
- Heavy material clamping fixtures
- Paper roll tensioning mechanisms
- Shipbuilding jig positioning
Installation guidelines:
Ensure maximum alignment tolerance <0.5mm/m. Requires weekly lubrication via built-in grease nipple (recommended ISO VG32 hydraulic oil). Adjust stroke only when cylinder is depressurized.
| Property | Property Value |
|---|---|
| sku | SGCJ200X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
