Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X1000-40S
$1,051.49
Regular price
$1,058.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGCJ200X1000-40S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) standard-compliant cylinder;
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
Installation guidelines:
Maintain 0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 45° angle,
mandatory use of counterbalance valves (CB-25 or equivalent) required. Lubricate rod weekly in high-cycle (>500 strokes/day) applications.
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X1000-40S Adjustable Cylinder Specifications
- Series: SGCJ200~250 Adjustable Stroke Cylinder
- Full model: SGCJ200X1000-40S
- Bore size: 200mm (8" industrial standard)
- Stroke: 1000mm (adjustable with ±5mm fine-tuning capability)
- Buffer type: External adjustable hydraulic cushion (40S suffix indicates special cushioning)
- Mounting style: MF1 front flange with rear trunnion (standard)
- Operating pressure: 0.05-1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Port size: G1-1/2 (ISO 1179-1 compliant)
- Cylinder material: Aluminum alloy body with chrome-plated piston rod
- Piston rod material: SCM435 steel (hard chrome plated, thickness ≥0.02mm)
- Seal material: NBR + PU combination seals
- Protection rating: IP54 (standard dust/water protection)
- Lubrication: Pre-lubricated (requires periodic relubrication every 500km stroke)
- Repeat positioning accuracy: ±0.5mm (under 0.5MPa)
- Max speed: 500mm/s (with cushion engaged)
- Weight: 25.5kg (excluding mounting accessories)
- Dimensions: 1350mm(L) × 220mm(W) × 220mm(H) (full extension)
- Load type: Suitable for radial loads ≤850kg (at mid-stroke)
- Accessory options: Magnetic piston (D-M9N), stroke sensor (SI-10), guide bush kit
Heavy-duty adjustable stroke cylinder with precision cushioning control, designed for high-mass applications requiring variable positioning. Features dual anti-rotation guides and impact-resistant end caps. The 40S variant includes enhanced cushioning valves for velocity ≥0.3m/s operations. Requires air filtration level 5μm.
Industrial Applications:
- Press machine die height adjustment systems
- Automotive welding fixture positioning
- Bulk material gate control in mining
- Injection molding machine ejector mechanisms
- Bridge segmental construction alignment
Installation guidelines:
Maintain 0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 45° angle,
mandatory use of counterbalance valves (CB-25 or equivalent) required. Lubricate rod weekly in high-cycle (>500 strokes/day) applications.
| Property | Property Value |
|---|---|
| sku | SGCJ200X1000-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
