Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X100-40
$244.23
Regular price
$251.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X100-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Installation note:
Align within 0.2mm perpendicularity tolerance during mounting.
Apply anti-seize compound (MoS2-based) on piston rod threads.
Perform 10-15 dry runs at 0.3MPa before full operation.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ125X100-40 Steel Pipe Adjustable Cylinder Specifications
- Model: SGJ125X100-40
- Type: Double-acting adjustable cushion cylinder (steel pipe structure)
- Bore size: Ø125mm
- Stroke: 100mm (adjustable ±5mm via external screws)
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Air cushion with adjustable shock absorber
- Port size: G3/8 (BSPP)
- Piston rod thread: M36×2
- Mounting type: Basic (MF12) with front flange
- Seal material: NBR + PU combination
- Tube material: Cold drawn precision steel pipe (STKM13A)
- Weight: 8.7kg ±2% (excluding accessories)
- Dimensions:
- Extended length: 310mm (minimum retracted: 210mm)
- Body diameter: Ø142mm (cylinder tube)
- Mounting flange: 180×180mm (square pattern)
High-rigidity industrial cylinder featuring dual-stage buffer adjustment and corrosion-resistant steel construction. The chrome-plated piston rod (hardness HRC45-50) withstands side loads in misalignment conditions. Requires 5μm filtered air with ISO VG32 lubricator for optimal performance.
Typical Applications:
- Press machine ejection systems
- Heavy-duty conveyor sorting gates
- Injection molding machine clamp units
- Automotive welding fixture positioning
- Shipbuilding plate bending equipment
Installation note:
Align within 0.2mm perpendicularity tolerance during mounting.
Apply anti-seize compound (MoS2-based) on piston rod threads.
Perform 10-15 dry runs at 0.3MPa before full operation.
| Property | Property Value |
|---|---|
| sku | SGJ125X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
