Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X100-75
$244.23
Regular price
$251.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Maintenance note:
Lubricate with ISO VG32 hydraulic oil through built-in grease fittings every 50km of stroke travel.
Avoid angular misalignment exceeding 0.5° during installation. Maximum side load capacity
reduces by 30% when operating at temperatures above 60℃.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Steel Pipe Adjustable Cylinder SGJ125X100-75 Technical Details
- Full model code: SGJ125X100-75 (Breakdown: SGJ=Steel Guide Cylinder, 125=Bore Ø125mm, 100=Stroke 100mm, 75=Adjustment Mechanism Code)
- Operating pressure range: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (Dry air required below 0℃)
- Cushion type: External adjustable rubber bumper (both ends)
- Mounting style: MF1 (Standard foot mounting with through-hole base)
- Port size: G3/8 (BSPP thread) dual ports
- Piston rod thread: M30×1.5 external thread (ISO metric standard)
- Tube material: Cold drawn precision steel pipe (STKM13A)
- Rod material: Chrome-plated carbon steel (S45C)
- Speed range: 50-750 mm/s (optimal performance at 200-500 mm/s)
- Max lateral load: 550N at full extension
- Corrosion resistance: Class CRC2 (standard chromium plating)
- Weight: Approximately 10.5 kg (without accessories)
- Dimensions:
- Total length: 355mm (base to rod end at full retraction)
- Stroke length: 100mm (±0.5mm tolerance)
- Outer diameter: 125mm (cylinder tube)
- Mounting base: 230mm(W) × 150mm(H) × 20mm(D)
Heavy-duty adjustable cylinder with steel-guided construction, featuring precision-machined stop collars for ±5mm stroke adjustment. The dual-cushion design reduces impact noise to <75dB(A) at 0.5MPa. Includes integrated mounting lugs and anti-rotation keyway (6mm width). Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
Industrial Applications:
- Material handling systems requiring precise position control
- Automotive welding fixture clamping mechanisms
- Injection molding machine ejector units
- Heavy conveyor gate actuators
- Paper processing equipment with high lateral load demands
Maintenance note:
Lubricate with ISO VG32 hydraulic oil through built-in grease fittings every 50km of stroke travel.
Avoid angular misalignment exceeding 0.5° during installation. Maximum side load capacity
reduces by 30% when operating at temperatures above 60℃.
| Property | Property Value |
|---|---|
| sku | SGJ125X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 100mm |
