Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X1000-10
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Steel Tube Adjustable Cylinder SGJ125X1000-10 Technical Specifications
- Model Code: SGJ125X1000-10
- Bore Size: 125mm (4.92")
- Stroke: 1000mm (39.37")
- Mounting Type: Adjustable front flange with integrated guide rails
- Operating Pressure: 0.05-0.8 MPa (7-116 PSI)
- Operating Temperature: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port Size: PT1/2 (BSPP) with anti-vibration thread coating
- Rod Material: Chrome-plated carbon steel (HRC50+ surface hardness)
- Tube Material: Cold drawn precision steel tube (Electrophoretic coating)
- Seals: HNBR compound with wear-resistant guide rings
- Weight: 24.8 kg (54.7 lbs) ±3%
- Dimensions: 1450mm(L) × 205mm(W) × 205mm(H)
- Rod End Thread: M20×1.5 male thread (ISO 12240-2 standard)
- Piston Speed: 50-800 mm/s (optimized for long stroke applications)
- ISO Standard: 15552 compliant (formerly ISO 6431)
Industrial-grade steel cylinder engineered for heavy-duty linear motion in extended stroke applications. Features dual-axis adjustable mounting flanges and precision ground rod for alignment stability. The electrophoretic coating provides corrosion resistance in humid environments (up to 95% RH non-condensing). Includes built-in magnet slots for position sensing compatibility.
- Automotive production line clamping fixtures
- Sheet metal press brake tool positioning
- Packaging machinery extended reach actuators
- Foundry equipment door actuators
- Solar panel array positioning systems
Installation note:
Maintain 0.2mm/m alignment tolerance during mounting. Requires weekly lubrication (VG32 hydraulic oil recommended) through integrated grease nipples. Avoid side load exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | SGJ125X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
