Airtac SGJ Steel Tube Type Adjustable Cylinder SGJ125X150-75
$259.38
Regular price
$266.88
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGJ125X150-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 15552 standard (formerly ISO 6431) for cylinder manufacturing;
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
Installation Note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locknut (AN-M20) to prevent piston rod rotation.
2. SG series adopts dual Y-type unidirectional piston seals with self-compensating design, delivering extended service life and low starting pressure. SGC series features space-saving asymmetric bidirectional seals with oil reservoir functionality;
3. SG series utilizes steel cylinder construction with exceptional impact resistance;
4. SGC series employs aluminum cylinder tubes compatible with optional magnetic piston position sensing (not available for SG series);
5. Precision adjustable pneumatic cushioning mechanism ensures smooth deceleration;
6. Comprehensive range of bore sizes and mounting accessories for flexible system integration;
7. High-temperature resistant seals enable reliable operation from 0°C to 150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGJ Adjustable Steel Cylinder Series
AirTAC SGJ Series Steel Tube Adjustable Cylinder SGJ125X150-75 Technical Details
- Model Code: SGJ125X150-75
- Cylinder Type: Double-acting adjustable stroke (steel tube construction)
- Bore Size: Ø125mm (±0.5mm tolerance)
- Stroke: 150mm (factory set, ±1mm adjustment range)
- Max. Operating Pressure: 1.0MPa (10bar)
- Medium Temperature: -20℃ to 80℃ (with NBR seals)
- Cushioning: Adjustable hydraulic shock absorber (3-stage)
- Mounting: MF1 series foot mounting standard (ISO 15552 compatible)
- Port Size: G1/2" (BSPP thread)
- Tube Material: Cold drawn precision steel tube (ST52.4)
- Rod Material: Hard chrome-plated steel (HCP-45)
- Weight: 18.7kg (without accessories)
- Dimensions:
- Extended Length: 150+2×75=300mm
- Body Diameter: Ø142mm (max. cross-section)
- Rod End Thread: M20×1.5 (male)
Industrial-grade adjustable stroke cylinder featuring heavy-wall steel construction with anti-corrosion phosphate coating. The triple-lip rod seal ensures 20,000km maintenance-free operation under ISO 6432 standards. Integrated magnetic piston allows for position sensing when paired with AT-06 series sensors.
Operation Guidelines:
- Requires 40μm filtered lubricated air (ISO 8573-1 Class 3.4.2)
- Buffer adjustment: Rotate cushion needle clockwise to increase damping
- Max side load: 650N at mid-stroke (with rigid guide)
- Press brake tool positioning systems
- Automotive welding fixture clamping
- Foundry equipment door actuators
- Palletizing robot end effectors
Installation Note:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locknut (AN-M20) to prevent piston rod rotation.
| Property | Property Value |
|---|---|
| sku | SGJ125X150-75 |
| Adjustable Stroke | 75mm |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | 150mm |
