Airtac SI100 Standard Cylinder SI100X10
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X10 Standard Cylinder Specifications
- Model: SI100X10
- Bore Size: 100 mm
- Stroke: 10 mm (customizable up to 1,000 mm)
- Operating Pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air buffer with shock absorber
- Temperature Range: -20℃ to 80℃
- Port Size: G3/8" (NPT1/2" optional)
- Piston Rod Thread: M16×1.5
- Mounting Types: Standard (MF1/MF2 front-flange, MP4 rear-pivot)
- Cylinder Tube: Hard anodized aluminum alloy
- Piston Rod: Chrome-plated stainless steel (SUS304)
- Seal Material: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 3.2 kg (bare cylinder without accessories)
- Dimensions: 215mm(L) × 100mm(W) × 100mm(H) (at 10mm stroke)
A heavy-duty ISO 15552 compliant cylinder featuring dual anti-rotation guides and IP65 protection. The hexagonal barrel design allows easy wrench tightening, while the 2mm-thick magnetic sensor slot enables precise position feedback. Optimized for high-cycle applications with 5,000km+ service life under rated conditions.
- Press machine clamping mechanisms
- Automated assembly line actuators
- Plastic injection molding ejectors
- Warehouse vertical lift systems
- CNC machine tool positioning
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. For vertical mounting,
add a mechanical lock nut to prevent rod rotation. Maintain 0.5mm minimum
clearance between magnetic sensor and cylinder body.
| Property | Property Value |
|---|---|
| sku | SI100X10 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
