Airtac SI100 Standard Cylinder SI100X100
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X100 Standard Cylinder Specifications
- Model: SI100X100
- Bore size: Ø100mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable air cushion (both ends)
- Port size: G3/8 (ISO standard)
- Mounting style: Basic type (MF1) with foot mounting holes
- Piston rod material: Hard chrome-plated steel
- Cylinder tube material: Aluminum alloy with oxidation treatment
- Seal material: NBR (Nitrile rubber)
- Piston speed: 50–800 mm/s
- Protection rating: IP54 (standard wipers)
- Lubrication: Pre-lubricated (Oil-free operation possible)
- Weight: 5.8 kg (±2%)
- Dimensions:
- Total length (L): 249mm (at mid-stroke position)
- Width (W): 132mm (including mounting feet)
- Height (H): 112mm (cylinder tube diameter)
A heavy-duty industrial cylinder designed for high-force linear motion applications. Features double-acting operation with corrosion-resistant construction and precision honed inner tube for smooth movement. The chrome-plated piston rod integrates wear-resistant seals capable of handling side loads, with magnetic version available (SI100X100-M9) for position sensing.
- Press machine clamping mechanisms
- Automated welding fixture positioning
- Foundry equipment door actuators
- Packaging line product ejection systems
- Plastic injection molding machine core pulls
Installation notes:
- Align cylinder axis with movement direction within ±2° tolerance
- Use flexible couplings for stroke-end force absorption
- For vertical mounting, implement anti-drop safety mechanism
- Lubricate rod weekly in high-cycle applications (>500 cycles/day)
| Property | Property Value |
|---|---|
| sku | SI100X100 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
