Airtac SI100 Standard Cylinder SI100X1000STC
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X1000STC Standard Cylinder Specifications
- Model: SI100X1000STC
- Type: ISO 15552 compliant double-acting cylinder
- Bore size: 100 mm
- Stroke: 1000 mm
- Operating pressure: 0.05–1.0 MPa (0.5–10 bar)
- Cushioning type: Adjustable hydraulic shock absorber (both ends)
- Piston speed: 50–800 mm/s
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (NPT1/2 optional)
- Mounting type: Basic MF1 (ISO 15552 mounting interfaces)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 9.8 kg (excluding rod end accessories)
- Dimensions:
- Extended length: 1268 mm
- Retracted length: 268 mm
- Body diameter: 125 mm
- Rod thread: M20×1.5
- Protection rating: IP54 (standard wipers)
- Lubrication: Pre-lubricated (Grease-free operation available)
High-force industrial cylinder engineered for heavy-duty linear motion applications. Features wear-resistant chromium plating and multi-layer sealing system for ≥5,000 km service life. The oversized cushioning mechanism reduces end-impact noise by 30% compared to standard models. Compatible with AT/SU series magnetic switches for position detection.
- Press machine ejection systems
- Automotive welding fixture positioning
- Plastic injection molding machine core pulls
- Steel coil handling equipment
- Paper roll clamping mechanisms
Installation note:
For full-stroke applications exceeding 800mm, support rails are recommended to prevent rod deflection.
Lubricate rod every 2,000 km of travel using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SI100X1000STC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
