Airtac SI100 Standard Cylinder SI100X100FA
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X100FA Standard Cylinder Specifications
- Model: SI100X100FA
- Bore size: 100mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting style: Front flange mounting (ISO 15552 standard)
- Port size: G3/8 (NPT1/4 optional)
- Piston rod thread: M20×1.5
- Ambient temperature: -20℃ to 80℃
- Cylinder tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR (Nitrile rubber)
- Piston rod material: Chrome-plated carbon steel
- Protection rating: IP54 (standard wiper design)
- Weight: 9.8kg ±2%
- Dimensions:
- Total length (extended): 378mm
- Body diameter: 112mm
- Flange mounting base: 160×160mm
- Rod end thread length: 30mm
A heavy-duty ISO-compliant pneumatic cylinder featuring double-acting operation and precision honed inner tube. The SI100X100FA combines high thrust force (785N at 0.5MPa) with corrosion-resistant construction, making it ideal for harsh industrial environments. Includes magnetic piston for sensor compatibility and anti-rotation rod design for precise linear motion.
- Plastic injection molding machine ejectors
- Automotive assembly line clamping fixtures
- Steel mill material handling systems
- Packaging machine press mechanisms
- Warehouse vertical lift actuators
Installation recommendation:
Use M12 mounting bolts (grade 8.8 or higher) for flange installation.
Maintain 0.5-1mm clearance between rod end and load during alignment.
Lubricate with ISO VG32 turbine oil if operating below -10℃.
- Relubricate every 500km of cumulative travel
- Inspect rod seals every 1 million cycles
- Replace cushion seals every 3 years in continuous operation
| Property | Property Value |
|---|---|
| sku | SI100X100FA |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
