Airtac SI100 Standard Cylinder SI100X100SN
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X100SN Standard Cylinder Technical Specifications
- Model: SI100X100SN
- Bore size: Ø100mm
- Stroke: 100mm
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-750 mm/s
- Cushioning type: Adjustable air cushion (both ends)
- Port size: Rc1/4 (G1/4 optional)
- Ambient temperature: -20℃ to 80℃
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Mounting type: Basic type (front flange standard)
- Weight: 9.8kg (with standard accessories)
- Dimensions: 318mm(L) × 125mm(W) × 125mm(H)
- ISO standard: 6432 compliant
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-torque industrial cylinder designed for heavy-duty linear motion applications. Features dual piston seals for enhanced leak prevention and tungsten-carbide treated rod bearings for extended service life. Optional magnetic piston version (SI100X100SN-M9) available for position sensing.
- Plastic injection molding machine ejectors
- Steel mill material clamping systems
- Automotive assembly line positioning
- Packaging machine compression units
- Foundry equipment actuation
Installation recommendation:
Use vibration-resistant mounting bolts (M12×1.75 grade 8.8 minimum) and
maintain 0.5-1mm alignment tolerance during rail mounting. Lubricate
rod surface weekly in high-cycle applications (>500 strokes/hour).
| Property | Property Value |
|---|---|
| sku | SI100X100SN |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
