Airtac SI100 Standard Cylinder SI100X1050
2. Piston sealing adopts reinforced Y-type radial seal structure with compensation capability, featuring extended service life and low dynamic friction;
3. Aerospace-grade aluminum tube with cross-reinforced structure and high-strength tie rods, delivering superior corrosion resistance;
4. Smooth adjustable cushioning mechanism for optimized stroke control;
5. Multiple cylinder specifications and mounting accessories available for flexible system integration.
Category: Standard Cylinders , Brand: AIRTAC , Series: SI100
AirTAC SI100X1050 Standard Cylinder Technical Specifications
- Model: SI100X1050
- Bore size: 100mm
- Stroke: 1050mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushioning type: Adjustable air cushion (both ends)
- Port size: G3/8 (NPT1/2 optional)
- Mounting type: Standard MF1 (basic front flange)
- Rod thread: M20×1.5 (external)
- Seal material: Polyurethane (NBR optional)
- Weight: 15.2kg (dry, without accessories)
- Dimensions:
- Total length: 1375mm (stroke + 162.5×2)
- Body diameter: 100mm
- Rod end bracket: 140×40mm
- Mounting hole spacing: 125×125mm
High-load industrial cylinder with extended stroke capability, featuring precision-ground chrome-plated rod (hardness HRC45-55) and aluminum alloy end caps. The double-acting design incorporates wear-resistant bearing bands and integrated magnet slots for sensor compatibility. Requires ISO 8573-1:2010 [3:4:3] class compressed air.
- Plastic injection molding machine ejectors
- Automotive press line material handling
- Steel coil stacking/unstacking systems
- Large-format CNC router hold-down mechanisms
- Packaging line palletizing arms
Installation guidelines:
Use alignment jigs during mounting to prevent side load. Lubricate with ISO VG32 hydraulic oil
during initial operation. Maintain 0.3mm minimum clearance between rod end and load during thermal expansion.
| Property | Property Value |
|---|---|
| sku | SI100X1050 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 1050mm |
