Airtac SI125 Standard Cylinder SI125X1000S
2. Piston features bidirectional Y-seal structure with cushioning function, offering extended service life and low friction resistance;
3. Aluminum barrel with cruciform reinforcement and black-anodized piston rod for enhanced corrosion resistance;
4. Precision machined cylinder surface ensures smooth operation;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI125
AirTAC SI125X1000S Standard Cylinder Specifications
- Model: SI125X1000S
- Type: ISO 15552 compliant single-acting/double-acting pneumatic cylinder
- Bore size: 125 mm
- Stroke: 1000 mm
- Operating pressure: 0.15–1.0 MPa
- Piston rod diameter: 40 mm (chromed steel)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting styles: Basic type (rear flange standard), optional foot/mid trunnion
- Port size: G1/2 (ISO 228/1 standard)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR/PU composite seals
- Tube material: Anodized aluminum alloy
- Weight: 21.5 kg (±5%)
- Dimensions: 1168mm(L) × 160mm(W) × 160mm(H)
- Protection rating: IP65 (standard wipers)
- Max theoretical force: 1471N @0.6MPa (double-acting)
High-thrust industrial cylinder engineered for heavy-duty linear motion applications. Features wear-resistant dual-seal technology and precision honed tube surface (Ra≤0.4μm). The extended stroke version incorporates reinforced rod guidance with dual bearings to prevent buckling. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Metal stamping press ejection systems
- Automotive assembly line positioning jigs
- Paper roll handling in converting machinery
- Injection molding machine core-pulling mechanisms
- Shipbuilding plate bending equipment
Installation note:
For horizontal mounting exceeding 800mm stroke, support brackets must be installed at 1/3 and 2/3 stroke positions.
Lubrication: Use ISO VG32 turbine oil with automatic lubricator (drip rate 1/50,000 cycle ratio).
| Property | Property Value |
|---|---|
| sku | SI125X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
