Airtac SI125 Standard Cylinder SI125X1000STC
2. Piston features bidirectional Y-seal structure with cushioning function, offering extended service life and low friction resistance;
3. Aluminum barrel with cruciform reinforcement and black-anodized piston rod for enhanced corrosion resistance;
4. Precision machined cylinder surface ensures smooth operation;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI125
AirTAC SI125X1000STC Standard Cylinder Specifications
- Model: SI125X1000STC
- Type: ISO 15552 compliant double-acting cylinder with magnetic piston
- Bore size: 125 mm
- Stroke: 1000 mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable air cushion at both ends
- Operating temperature: -20℃ to 80℃
- Port size: G3/8 (M14×1.5 optional)
- Mounting style: Standard ISO mounting (VDI/VDE 3845 optional)
- Cylinder tube material: Anodized aluminum alloy
- Piston rod material: Hard chrome-plated steel (Cr-Mo alloy)
- Seal material: NBR/PU hybrid seals
- Weight: 12.8 kg (without accessories)
- Dimensions: 1250mm(L) × 180mm(W) × 180mm(H) (fully extended)
- Rod end thread: M20×1.5 (male)
- Protection rating: IP65 (standard wipers)
- Max theoretical force: 1570N @ 0.63MPa
High-performance industrial cylinder engineered for heavy-duty linear motion applications requiring extended stroke precision. Features dual adjustable pneumatic cushions for smooth deceleration and reinforced rod bearing for lateral load resistance. Compatible with ATEX Zone 2 environments when configured with brass accessories.
- Automotive assembly line clamping systems
- Plastic injection molding machine ejectors
- Steel mill material handling gates
- Paper processing equipment actuators
- Shipbuilding fixture positioning
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use rod-end support brackets (ASD12-125 recommended). Lubricate through air supply (ISO VG32 equivalent)
at 1 drop/m³ airflow for optimal seal life.
Critical note:
When operating at maximum stroke under full load, ensure cycle rate remains below 80% of calculated
maximum (use formula: 15000/(2×stroke[mm])) to prevent overheating. Install magnetic sensors at ≥50mm
distance from cylinder body in high EMI environments.
| Property | Property Value |
|---|---|
| sku | SI125X1000STC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | <1000mm> |
