Airtac SI125 Standard Cylinder SI125X100SFTC
2. Piston features bidirectional Y-seal structure with cushioning function, offering extended service life and low friction resistance;
3. Aluminum barrel with cruciform reinforcement and black-anodized piston rod for enhanced corrosion resistance;
4. Precision machined cylinder surface ensures smooth operation;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI125
AirTAC SI125X100SFTC Standard Cylinder Specifications
- Model: SI125X100SFTC
- Bore size: Ø125mm
- Stroke: 100mm (customizable: 25-1000mm)
- Operating pressure: 0.15–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable buffer at both ends
- Mounting type: Basic foot mounting (MF1) with optional front flange/rod flange
- Port size: G3/8 (BSPP thread)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Aluminum alloy with hard anodizing
- Seals: NBR (standard), optional FKM for high temp
- Weight: 12.5kg (excluding accessories)
- Dimensions: 307mm(L) × 140mm(W) × 140mm(H) (retracted length)
- Max theoretical thrust: 1533N @0.5MPa
- Protection rating: IP65 (dust-tight & water jet resistant)
- ISO standard: 15552 compliant
High-force industrial cylinder with precision-guided piston, featuring wear-resistant construction and dual cushioning adjustment. The square-shaped body design enhances stability during side load operations. Includes built-in magnet for position sensing compatibility (sensor not included). Requires 40μm filtered air with ISO 8573-1:2010 class 4.3.4 purity.
- Press machine ejection systems
- Automotive welding fixture clamping
- Heavy-duty conveyor gate control
- Plastic injection molding machine core pulling
- Steel mill roller adjustment mechanisms
Installation notes:
- Allow 15mm minimum clearance for rod extension
- Use Loctite 243 on mounting threads
- Lubricate with ISO VG32 hydraulic oil if non-lubricated air used
- Align within 0.2mm angular misalignment tolerance
| Property | Property Value |
|---|---|
| sku | SI125X100SFTC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
