Airtac SI125 Standard Cylinder SI125X100TC
2. Piston features bidirectional Y-seal structure with cushioning function, offering extended service life and low friction resistance;
3. Aluminum barrel with cruciform reinforcement and black-anodized piston rod for enhanced corrosion resistance;
4. Precision machined cylinder surface ensures smooth operation;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AIRTAC | Series: SI125
AirTAC SI125X100TC Standard Cylinder Specifications
- Model: SI125X100TC
- Bore size: 125mm
- Stroke: 100mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: Front/rear flange (TF1/TF2), foot mounting (MP4)
- Port size: G3/8 (standard), optional NPT1/2
- Piston rod thread: M20×1.5 (standard)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Carbon steel (hard chrome plated)
- Seals: NBR (standard), optional Viton
- Weight: 3.8kg (excluding accessories)
- Dimensions:
- Extended length: 293mm
- Retracted length: 193mm
- Body diameter: 125mm
- Mounting hole spacing: 160mm (front flange)
High-force pneumatic cylinder designed for heavy-duty industrial automation. Features double-acting operation with magnetic piston for position sensing compatibility (sensor not included). The corrosion-resistant construction and multi-lip rod seal ensure reliable performance in dusty or humid environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Metal stamping press ejection systems
- Plastic injection molding machine clamping
- Automotive assembly line positioning
- Heavy material handling in logistics
- Paper processing equipment actuation
Installation tips:
Align cylinder axis with load direction within ±0.5° tolerance.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air.
Avoid side loads exceeding 150N. For vertical mounting,
use locking nut (AN7) to secure piston rod.
Critical parameters:
Maximum thrust force 9,800N at 0.7MPa.
Do not exceed 1.0MPa with full stroke operation.
Cycle rate limited to 85% duty cycle at maximum speed.
| Property | Property Value |
|---|---|
| sku | SI125X100TC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | PT 1/2 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | 100mm |
