Airtac SI160 Standard Cylinder SI160X1000S
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X1000S Standard Cylinder Specifications
- Model: SI160X1000S
- Bore size: 160mm
- Stroke: 1000mm
- Operating pressure: 0.15–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: G1/2 (ISO standard)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Operating medium: Dry air (ISO8573-1:2010 Class 3.4.3)
- Material: Aluminum alloy barrel, hardened steel piston rod
- Seal material: NBR (nitrile butadiene rubber)
- Mounting style: Standard MF1 (front flange) with optional accessories
- Protection rating: IP65 (rod seal area)
- Weight: 18.5 kg ±2%
- Dimensions:
- Total length (L): 1276mm (stroke + 276mm)
- Body diameter (W): 185mm (max cylinder OD)
- Height with mounts (H): 225mm (including flange protrusions)
High-force industrial cylinder designed for heavy-duty linear motion applications. Features double-acting operation with chromium-plated piston rod (H5 tolerance) for wear resistance. The extended stroke version incorporates reinforced rod guidance to prevent buckling, with magnetic piston option (SI160X1000S-M9) for position sensing.
- Press machinery force generation
- Automotive assembly line clamping
- Steel coil handling systems
- Plastic injection molding ejectors
- Shipbuilding positioning fixtures
Installation note:
Requires lateral support brackets (ASNU16-200 recommended) when mounted horizontally.
Lubrication: Initial grease filling lasts 100km stroke distance; replenish with ISO VG32
turbine oil thereafter. Avoid side loads exceeding 200N on rod end.
- 5 million cycles (standard conditions)
- 2 million cycles (high-load @ 0.8MPa continuous)
- Rod seal replacement recommended every 10,000 operating hours
| Property | Property Value |
|---|---|
| sku | SI160X1000S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
