Airtac SI160 Standard Cylinder SI160X100STC
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X100STC Standard Cylinder Specifications
- Model: SI160X100STC
- Type: Double-acting with magnetic switch (ISO 6432 compliant)
- Bore size: 160mm
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port thread: G1/2 (BSPP standard)
- Piston rod material: Chrome-plated carbon steel (HRC 45-50)
- Tube material: Anodized aluminum alloy (6063-T5)
- Seals: NBR (Nitrile) standard, optional FKM/Viton for high temp
- Ambient temperature: -20℃ to 80℃ (non-freezing conditions)
- Weight: 3.85kg ±2% (excluding accessories)
- Dimensions: 220mm(L) × 160mm(W) × 160mm(H) (stroke extended)
- Rod thread: M20×1.5 (external)
- Max theoretical force: 18,086N @0.9MPa (extend side)
- Air consumption: 2.01L/stroke @0.5MPa
- ISO standard: 6432 (mounting dimensions compatible)
High-thrust industrial cylinder featuring precision honed tubing and triple lip seals for leak-free operation. The hardened piston rod with multi-layer chrome plating resists scoring in contaminated environments. Integrated T-slot mounting grooves enable flexible installation configurations. Requires 40µm filtered lubricated air (ISO 8573-1 class 4.4.3).
- Metal stamping press ejection systems
- Automotive welding fixture clamping
- Injection molding machine core pulls
- Heavy-duty conveyor gate actuators
- Paper mill roller positioning
Installation guidelines:
Align rod axis within ±0.5° angular misalignment. Use rod end support when stroke/rod length ratio exceeds 10:1.
Magnetic switch wiring must maintain 30cm separation from high-voltage cables.
| Property | Property Value |
|---|---|
| sku | SI160X100STC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 160mm |
| Stroke | 100mm |
