Airtac SI160 Standard Cylinder SI160X10S
2. NBR Y-shaped piston sealing structure with integrated cushioning mechanism, featuring long service life and low friction coefficient
3. Precision-milled aluminum tube with black-hardened piston rod for enhanced corrosion resistance
4. Smooth operation with adjustable cushioning mechanism
5. Multiple cylinder specifications and comprehensive mounting accessories available for flexible system integration
Category: Standard Cylinders , Brand: AIRTAC , Series: SI160
AirTAC SI160X10S Standard Cylinder Specifications
- Model: SI160X10S
- Bore size: 160mm
- Stroke: 10mm (Customizable: 10-500mm)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Air cushion (adjustable buffer at both ends)
- Mounting style: Basic type (MF1) with optional accessories for LB, MP4, or MP2 mounts
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Cylinder material: Aluminum alloy barrel (hard anodized), steel piston rod (chrome-plated)
- Seal material: NBR (standard), optional FKM for high-temperature applications
- Weight: 4.8 kg ±2% (without accessories)
- Dimensions: 248mm(L) × 160mm(Bore Ø) × 85mm(H) (at mid-stroke position)
- Rod thread: M20×1.5 (external)
- ISO standard: 15552 compliant
- Protection rating: IP65 (standard wipers)
High-force pneumatic cylinder designed for heavy-duty industrial applications. Features precision honed tubing and multi-layered sealing system for minimal air consumption. Dual cushioning mechanism reduces end-impact noise by 30% compared to basic models. Optional magnetic piston version (SI160X10S-M9) available for position sensing.
- Press machine ejection systems
- Automotive welding fixture clamping
- Heavy conveyor gate actuation
- Plastic injection molding machine core pulling
- Steel mill roller positioning
Installation note:
Lubricate piston rod with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum alignment tolerance during mounting.
Use locknuts with 35-45 N·m torque for rod-end connections.
| Property | Property Value |
|---|---|
| sku | SI160X10S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | S-Magnetic |
| Bore Diameter | 160mm |
| Stroke | <10mm> |
