Airtac SI40 Standard Cylinder SI40X100TC
2. Features wear-resistant Y-shaped axial sealing structure with cushioning function, extended service life, and low friction resistance;
3. Aluminum square tube profile with anodized tie rods for superior corrosion resistance;
4. Built-in adjustable pneumatic cushioning at both ends;
5. Multiple cylinder specifications and mounting accessories available for flexible configurations.
Category: Standard Cylinders | Brand: AirTAC | Series: SI40
AirTAC SI40X100TC Standard Cylinder Specifications
- Model: SI40X100TC
- Type: ISO 6432 compliant single-acting/double-acting cylinder
- Bore size: 40 mm
- Stroke: 100 mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable air cushion (both ends)
- Port size: 1/4" NPT or G1/8 (optional)
- Mounting options: Basic MF1/MF2/MB1/MB2/MC1 series brackets
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Max theoretical thrust: 503N @0.63MPa (double-acting)
- Weight: Approximately 1.65 kg (without accessories)
- Dimensions:
- Total length: ~196 mm (at mid-stroke position)
- Extended length: ~296 mm (full stroke)
- Retracted length: ~196 mm
- Outer diameter: 50 mm
- Mounting height: 18.5 mm (front) / 33 mm (rear)
The SI40X100TC features a compact yet robust design with precision-machined components, offering smooth linear motion with minimal stick-slip effect. Its dual adjustable cushions reduce end-impact noise while providing ±3mm cushion stroke adjustment. The corrosion-resistant construction ensures reliable performance in humid environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automated packaging line clamping mechanisms
- CNC machine tool chip conveyors
- Automotive assembly line part positioning
- Printing press paper feed systems
- Food processing equipment actuators (with optional FDA seals)
Installation note:
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air.
Avoid side load exceeding 15N·m. For vertical mounting,
use double-acting configuration with speed controller to prevent piston slam.
| Property | Property Value |
|---|---|
| sku | SI40X100TC |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
