Airtac SI50 Standard Cylinder SI50X100H
2. Piston features a durable Y-type axial seal with self-compensating function, providing extended service life and low friction resistance
3. Aluminum tube with crisscross reinforcement design and anodized tie rods for enhanced corrosion resistance
4. Adjustable cushioning for smooth operation
5. Multiple configurations available with comprehensive cylinder variants and mounting accessories for flexible system integration
Category: Standard Cylinders | Brand: AirTAC | Series: SI50
AirTAC SI50X100H Standard Cylinder Technical Specifications
- Model: SI50X100H
- Type: ISO 6432 compliant single-acting/push type
- Bore size: Ø50 mm (±0.1mm tolerance)
- Stroke: 100 mm (adjustable ±2mm)
- Operating pressure: 0.1-0.9 MPa (15-130 PSI)
- Ambient temperature: -20℃ to 80℃ (NBR seals)
- Cushioning: Adjustable pneumatic cushion (3-stage)
- Port size: G1/4 (ISO 228-1 standard)
- Piston rod thread: M16×1.5 (10.9 grade steel)
- Mounting: Front flange with through holes (ISO 15552)
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- End caps: Die-cast aluminum (ALUCORE™ treatment)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: Oil-resistant NBR (Option: FKM for high temp)
- Weight: 2.35 kg (without accessories)
- Dimensions:
- Total length: 218 mm (at full retraction)
- Stroke length: 100±0.5 mm
- Mounting face: 72×72 mm square
- Rod end thread depth: 15 mm
Industrial-grade pneumatic cylinder featuring wear-resistant dual-seal technology and precision honed bore. The triple-lip rod seal design ensures ≤0.5 mm³/min air leakage. Includes magnetic piston (DIN 43650) for position sensing compatibility. Pre-lubricated with ISO VG32 equivalent grease for 5,000km service life.
- Plastic injection molding machine ejectors
- CNC fixture clamping systems
- Automotive assembly line actuators
- Packaging machine pusher mechanisms
- Textile machinery tension control
Installation guidelines:
Apply 24-28 N·m torque on mounting bolts. Maintain 0.5mm alignment tolerance.
For vertical mounting, use model SI50X100H-V with reinforced rod bearing.
Lubricate every 50,000 cycles under normal load.
- Max thrust: 785N @ 0.7MPa
- Piston speed: 50-700 mm/s
- Cycle rate: ≤90% duty cycle @ 2Hz
- Cushion adjustment range: 5-20mm
| Property | Property Value |
|---|---|
| sku | SI50X100H |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
