This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAI50X1050S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SI50 Standard Cylinder SI50X1050S
The AirTAC SI50 Standard Cylinder SI50X1050S is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø50mm bore and 1050mm stroke, G1/4 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAI50X1050S, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ50 mm
- Stroke1050 mm
- Port sizeG1/4
- Acting typeDouble acting
- Rod threadM16×1.5
- StatusDiscontinued → SAI50X1050S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SI50 Standard Cylinder SI50X1050S
The AirTAC SI50X1050S is a discontinued double-acting ISO 15552 profile cylinder with a 50mm bore and 1050mm stroke. It delivers 982N push force at 0.5MPa via a G1/4 port. AirTAC replaced this legacy unit with the SAI50X1050S, a direct upgrade retaining the exact ISO 15552 mounting interface, bore, stroke, and output force.
The SAI replacement features an upgraded piston seal with two Y-shaped one-way elements for low start-up pressure and long life. The SAI family also introduces SAIL, SAIF, and BSAI lock variants absent in the SI line. This -S SKU includes a piston magnet for CS1-B/DS1-B sensors.
Airtac SI50 Standard Cylinder SI50X1050S Technical Specifications
| Model | Airtac SI50 Standard Cylinder SI50X1050S |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAI50X1050S |
| Bore size | Ø50 mm |
| Stroke | 1050 mm |
| Acting type | Double acting |
| Port size | G1/4 |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max standard stroke | Up to 1200 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAI50X1050S carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 825 N |
| 0.7 MPa | 1374 N | — |
| Max (@1.0 MPa) | 200 kgf | |
The SAI50X1050S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SI50 Standard Cylinder SI50X1050S
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 50 | Bore size in mm. |
| ×1050 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SI50 Standard Cylinder SI50X1050S Is Used
Long-Stroke Diversion
Drives large package pushers across wide conveyor belts over the full 1050mm travel.
Vertical Material Lift
Hoists 50kg palletized bins between floor levels using external linear guides.
Automated Door Control
Opens heavy industrial blast doors or machine guards requiring extended reach.
Replacing the Airtac SI50 Standard Cylinder SI50X1050S with the SAI50X1050S
To replace the SI50X1050S, order the SAI50X1050S. Verify your ISO 15552 mounting accessories (LB, FA, TC, etc.), the G1/4 port, and the M16x1.5 rod thread. Because this is a long 1050mm stroke, use external guides to prevent rod bending and side-load damage. If sizing up, the 63mm bore yields 1559N at 0.5MPa; sizing down, the 40mm bore yields 628N. A plain cylinder drifts on air loss—the cushion only decelerates. For load holding, use an external rod lock, pilot check valve, or the SAIL/BSAI lock variant. The -S magnet works with legacy CS1-B/DS1-B switches; the SAI uses current AirTAC switches.
Replacement checklist
- ✓ Same ISO 15552 interface → SAI50X1050S
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SI50 Standard Cylinder SI50X1050S FAQ
Yes, the SI50X1050S is discontinued. The direct replacement is the SAI50X1050S. It is dimensionally interchangeable per ISO 15552, matching the 50mm bore, 1050mm stroke, G1/4 port, and mounting fixtures.
The 50mm bore uses a G1/4 port. It generates 982N push and 825N pull at 0.5MPa, 1374N push at 0.7MPa, and a theoretical max of 200kgf at 1.0MPa. Speed is 30-800mm/s.
