Airtac SI63 Standard Cylinder SI63BX100H
2. Piston sealing features dual-locked Y-type axial sealing structure with dust scraping capability, delivering extended service life and low friction resistance;
3. Aluminum tube with cross-shaped reinforcement and anodized tie rods for enhanced corrosion resistance;
4. Optimized cushion adjustment system with stable stroke control;
5. Multiple bore sizes and mounting accessories available for flexible configuration.
Category: Standard Cylinders | Brand: Airtac | Series: SI63
AirTAC SI63BX100H Standard Cylinder Specifications
- Model: SI63BX100H
- Type: ISO 6432 compliant double-acting pneumatic cylinder
- Bore size: Ø63 mm (±0.1mm manufacturing tolerance)
- Stroke: 100 mm (adjustable cushioning at both ends)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Piston rod thread: M16×1.5 (external)
- Port size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable rubber buffer + shock absorber
- Mounting style: Basic type (multiple mounting options via accessory kits)
- Piston material: Extruded aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Seal type: NBR seals with wear-resistant ring
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Max speed: 500-800 mm/s (dependent on load and cushioning)
- Weight: 2.4 kg (±3% tolerance)
- Dimensions:
- Length: 225 mm (full retracted)
- Width: 82 mm (including mounting bosses)
- Height: 82 mm (square body profile)
- Protection rating: IP65 (standard wiper seal)
High-precision industrial cylinder featuring dual anti-rotation design and corrosion-resistant construction. The SI63BX100H combines 500,000+ cycle durability with precise linear motion control through optimized seal geometry and hardened guide bands. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
- Automated material handling systems
- Plastic injection molding machine ejectors
- Automotive assembly line clamping devices
- Food packaging machine actuators (food-grade grease option available)
- CNC machine tool positioning mechanisms
Installation guidance:
Maintain 0.05mm maximum misalignment during mounting. Lubricate through port with ISO VG32 hydraulic oil
(1-2 drops per cycle) if operating below 0.5 MPa. Allow 20mm clearance behind rod end for maintenance.
| Property | Property Value |
|---|---|
| sku | SI63BX100H |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS304 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
