Airtac SI63 Standard Cylinder SI63BX120S
2. Piston sealing features dual-locked Y-type axial sealing structure with dust scraping capability, delivering extended service life and low friction resistance;
3. Aluminum tube with cross-shaped reinforcement and anodized tie rods for enhanced corrosion resistance;
4. Optimized cushion adjustment system with stable stroke control;
5. Multiple bore sizes and mounting accessories available for flexible configuration.
Category: Standard Cylinders | Brand: Airtac | Series: SI63
AirTAC SI63BX120S Standard Cylinder Specifications
- Model: SI63BX120S
- Type: ISO 6432 compliant double-acting cylinder
- Bore size: Ø63 mm (±0.1mm machining tolerance)
- Stroke: 120 mm (adjustable cushioning ±10%)
- Operating pressure: 0.15–1.0 MPa (1.5–10 bar)
- Piston speed: 50–800 mm/s (lubricated operation)
- Ambient temperature: -20℃ to 80℃
- Cushioning type: Air cushion adjustable via needle valves
- Mounting style: Basic type (multiple options available: MA/MS/MP)
- Port size: G3/8 (BSPP thread)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Seal material: NBR (nitrile) with wear-resistant ring
- Weight: 2.45 kg (excluding accessories)
- Dimensions:
- Total length: 298 mm (at full retraction)
- Body diameter: Ø63 mm ±0.5
- Mounting base: 100×50 mm (front flange pattern)
- Rod end thread: M16×1.5 (male)
High-rigidity industrial cylinder featuring wear-compensation seals and anti-rotation piston rod. The anodized barrel resists chemical corrosion and minimizes internal scoring. Designed for medium-duty cycles (up to 5 million strokes) with 0.5mm rod runout tolerance. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Automated assembly line clamping mechanisms
- Plastic injection molding ejector systems
- CNC machine tool door actuators
- Food processing conveyor gate controls
- Automotive welding fixture positioning
Installation notes:
- Align cylinder axis within 0.2° angular misalignment tolerance
- Maintain 1.5× bore diameter clearance for rod extension space
- Use copper-free anti-seize compound on rod threads
- Install air filter-regulator-lubricator (FRL) unit upstream
| Property | Property Value |
|---|---|
| sku | SI63BX120S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS304 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 120mm |
