Airtac SI63 Standard Cylinder SI63BX130S
2. Piston sealing features dual-locked Y-type axial sealing structure with dust scraping capability, delivering extended service life and low friction resistance;
3. Aluminum tube with cross-shaped reinforcement and anodized tie rods for enhanced corrosion resistance;
4. Optimized cushion adjustment system with stable stroke control;
5. Multiple bore sizes and mounting accessories available for flexible configuration.
Category: Standard Cylinders | Brand: Airtac | Series: SI63
AirTAC SI63BX130S Standard Cylinder Technical Specifications
- Model: SI63BX130S
- Bore size: 63 mm
- Stroke: 130 mm
- Action type: Double-acting
- Operating pressure: 0.1-1.0 MPa (14.5-145 psi)
- Piston speed: 50-800 mm/s
- Cushioning: Adjustable hydraulic buffer (both ends)
- Port size: G1/8 (ISO 228/1 standard)
- Mounting type: ISO 15552 compliant (multiple options available)
- Piston rod material: Hard chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: Nitrile rubber (NBR) standard
- Temperature range: -20℃ to +80℃
- Protection class: IP65 (dust-tight & protected against water jets)
- Weight: 1.85 kg ±2%
- Dimensions (L×W×H):
- Total length: 190 mm (stroke 130 + 60 mm end caps)
- Cross-section: 76 mm × 76 mm
- Rod end thread: M16×1.5
- Optional features: Magnetic piston (SI63BX130S-M9N available)
High-precision industrial cylinder with ISO-standard mounting patterns, designed for repetitive heavy-load applications. Features enhanced wear resistance through multi-layer chrome plating and precision honed tube. The dual cushioning system reduces end-impact noise to ≤70 dB(A) at 0.5 MPa. Compatible with auto-switch sensors via T-slot mounting.
- Automated assembly line clamping mechanisms
- Die-casting machine ejection systems
- Packaging machine pusher arms
- Automotive welding fixture positioning
- Plastic injection molding machine core pulls
Installation recommendations:1. Use locknuts with 25-30 N·m torque for rod-end connections
2. Maintain 0.3-1.0 MPa lubrication pressure for optimal seal life
3. Allow 5° maximum angular misalignment in mounting
4. Replace lubricator elements every 3,000 km of cumulative stroke
- Relubricate every 500,000 cycles (standard duty)
- Inspect buffer adjustment every 3 months
- Maximum side load: 140 N at full extension
| Property | Property Value |
|---|---|
| sku | SI63BX130S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Piston Rod Material | SUS304 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 130mm |
