This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAID32X125, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SID Series Double-Rod Cylinder SID32X125
The AirTAC Airtac SID Series Double-Rod Cylinder SID32X125 is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø32mm bore and 125mm stroke, G1/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAID32X125, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke125 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAID32X125
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SID Series Double-Rod Cylinder SID32X125
The AirTAC SID32X125 is a double-acting, double-rod ISO 15552 cylinder where a rod exits both ends, yielding equal push and pull force (345 N @0.5 MPa). Because both faces use the rod-side area, it resists rotation and can drive two tools. This discontinued model drops directly into the SAID32X125, sharing the G1/8 port, M10x1.25 thread, and 27 mm cushion.
The SAID32X125 successor retains the exact ISO 15552 mounting interface and introduces an upgraded two-piece Y-shaped piston seal for lower start-up pressure. Without a -S suffix, this SKU lacks a magnet and cannot carry a sensor.
Airtac SID Series Double-Rod Cylinder SID32X125 Technical Specifications
| Model | Airtac SID Series Double-Rod Cylinder SID32X125 |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAID32X125 |
| Bore size | Ø32 mm |
| Stroke | 125 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAID32X125 carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAID32X125 produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SID Series Double-Rod Cylinder SID32X125
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SID Series Double-Rod Cylinder SID32X125 Is Used
Synchronized Transfer
Drives two opposing grippers to center and transfer thin workpieces simultaneously, using equal both-ways force to maintain balanced handling.
Anti-Rotation Indexing
Moves a small machining fixture without rotational drift, relying on the dual rods to prevent yaw during rapid 30-800 mm/s positioning.
Dual-Tool Actuation
Powers a push assembly on the front face while the rear rod trips a mechanical cam, coordinating two machine actions in one stroke.
Replacing the Airtac SID Series Double-Rod Cylinder SID32X125 with the SAID32X125
Replace the discontinued SID32X125 with the direct replacement SAID32X125, reusing your existing FA, LB, or TC mounts. Size both directions by equal force: if 345 N @0.5 MPa is insufficient, step up to the 40 mm bore (528 N) or down to a smaller bore. Choose a double-rod cylinder when you need anti-rotation stability or a back rod to carry a sensor cam. This non-magnetic SKU cannot take a switch; add the -S suffix on the SAID for legacy CS1-B/DS1-B sensor accuracy. For this 125 mm stroke, side-load is minimal, but for strokes >=300 mm ensure guide alignment to prevent binding.
Replacement checklist
- ✓ Same ISO 15552 interface → SAID32X125
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SID Series Double-Rod Cylinder SID32X125 FAQ
Yes, the SID32X125 is discontinued. The direct replacement is the SAID32X125, which shares the same ISO 15552 interface, 32 mm bore, 125 mm stroke, G1/8 port, and equal both-ways force.
Force is equal both ways: 345 N @0.5 MPa, 483 N @0.7 MPa, and 621 N @0.9 MPa. It operates at 0.15-1.0 MPa, runs at 30-800 mm/s, and uses a G1/8 port with M10x1.25 rod threads. The air cushion only decelerates; use an external rod lock for load holding.
