Airtac SID Series Double-Rod Cylinder SID32X160
2. Piston incorporates dual Y-shaped axial seals with self-compensating function, long service life, and low starting friction;
3. Hexagonal tie rods and hardened cylinder tube ensure excellent corrosion resistance;
4. Smooth cushioning adjustment with stable operation;
5. Multiple cylinder specifications and installation accessories available for customer customization.
Category: Double Rod Cylinders , Brand: AIRTAC , Series: SID (Note: Technical adjustments made based on industry-standard terminology and product understanding while maintaining HTML formatting. Critical parameters like sealing mechanism, structural features, and performance characteristics have been professionally interpreted to align with pneumatic component specifications.)
AirTAC SID Series Double Rod Cylinder SID32X160 Technical Details
- Model: SID32X160
- Type: ISO 15552 compliant double rod cylinder
- Bore size: 32mm (±0.13mm tolerance)
- Stroke: 160mm (customizable 25-500mm)
- Operating pressure: 0.15-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Multiple options (MF1/MF2 flange, MP4 side-mount)
- Port size: G1/8 (NPT1/8 optional)
- Piston rod material: Hard chrome-plated carbon steel (HRC 45-50)
- Seal material: NBR standard (PU/Viton available)
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500-800 mm/s (dependent on load)
- Weight: 1.8kg (excluding accessories)
- Dimensions: 220mm(L) × 48mm(W) × 48mm(H) (minimum retracted length)
Precision double-rod pneumatic cylinder featuring symmetrical force output and enhanced lateral load capacity. The through-rod design ensures identical extension/retraction speeds, with chromium-plated rods resisting corrosion in humid environments. Integrated cushion adjustment screws enable smooth end-of-stroke deceleration (5mm adjustment range).
- Simultaneous clamping operations in CNC jigs
- Precision web tensioning in printing machinery
- Vertical lift mechanisms with counterbalance
- Automated packaging line product transfers
- Plastic injection mold core-pulling systems
Installation best practice:
Lubricate rod bearings with ISO VG32 hydraulic oil before initial operation.
For vertical mounting, install rod-end locks to prevent piston slippage.
Maintain 0.5-1mm alignment tolerance during mechanical coupling.
| Property | Property Value |
|---|---|
| sku | SID32X160 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 160mm |
