Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-10
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X100-10 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ100X100-10
- Type: Double rod, dual-axis adjustable pneumatic cylinder
- Bore size: 100mm
- Stroke: 100mm (adjustable via stopper mechanism)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (axial foot/rod flange optional)
- Port size: G1/2 (ISO 228/1 standard)
- Rod material: Hard chrome-plated steel
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile rubber) standard / PU optional
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
- Weight: 8.7 kg (bare cylinder) / 9.2 kg (with standard accessories)
- Dimensions:
- Body length: 344mm (excluding rods)
- Stroke-adjusted max length: 444mm
- Rod diameter: 25mm (per rod)
- Mounting hole spacing: 160mm × 160mm
High-precision dual-axis cylinder with integrated position locking mechanism, designed for applications requiring precise linear motion and anti-rotation stability. Features symmetrical load distribution through parallel rod configuration and tungsten carbide-coated guide shafts. Includes magnetic piston for position sensing compatibility (sensor not included). Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Precision fixture positioning in CNC machining centers
- Vertical lifting mechanisms for robotic palletizers
- Parallel gripper actuation in pick-and-place systems
- Press tool alignment in automotive stamping lines
- Optical component positioning stages
Installation guidelines:
- Align within 0.2mm/m parallel tolerance during mounting
- Apply ISO VG32 hydraulic oil for initial lubrication
- Allow 50mm clearance around adjustment screws for maintenance
- Lock stopper nuts with 25N·m torque after position setting
| Property | Property Value |
|---|---|
| sku | SIJ100X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
