Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-50H
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X100-50H Double Rod Adjustable Cylinder Specifications
- Model: SIJ100X100-50H
- Type: Double rod, adjustable stroke pneumatic cylinder
- Bore size: Ø100 mm
- Stroke: 100 mm (adjustable via external stoppers)
- Rod diameter: Ø25 mm (both rods)
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable rubber buffers on both ends
- Mounting style: Front flange with ISO 15552 mounting holes
- Port size: G3/8 (standard) or optional NPT1/2
- Ambient temperature: -20℃ to 80℃
- Piston material: Anodized aluminum alloy
- Rod material: Hard chrome-plated steel
- Seals: NBR (standard) / Optional FKM for high temps
- Weight: 6.8 kg (dry, without accessories)
- Dimensions: 400mm(L) × 135mm(W) × 135mm(H) (at mid-stroke)
- Max theoretical force: 785 N @ 0.63 MPa
- ISO standard: 15552 (previously ISO 6431)
A heavy-duty twin rod cylinder featuring dual-axis stability and external stroke adjustment. The symmetrical rod design eliminates lateral torque for precision alignment in demanding applications. Equipped with wear-resistant scrape seals for dirty environments. Requires 40μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
- Precision press tool positioning systems
- Automotive welding fixture clamping
- Glass handling vacuum plate manipulators
- Injection molding machine ejector mechanisms
- Heavy conveyor gate actuators
Installation tip:
Mount using alignment jigs to ensure parallel rod movement.
For variable stroke applications, secure stopper bolts with thread-locking compound.
Lubricate guide shafts monthly in continuous operation.
| Property | Property Value |
|---|---|
| sku | SIJ100X100-50H |
| Adjustable Stroke | <50mm> |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
