Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-10
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-10 Double Rod Adjustable Cylinder Specifications
- Model: SIJ100X1000-10
- Type: Double rod adjustable stroke cylinder (ISO 15552 standard)
- Bore size: Ø100mm
- Stroke: 1000mm (adjustable with built-in stroke adjustment mechanism)
- Operating pressure: 0.2–1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Rod diameter: Ø25mm (chrome-plated steel)
- Mounting type: Basic type (multiple mounting options available via accessories)
- Weight: 12.8kg ±2% (without accessories)
- Dimensions: 1315mm(L) × 122mm(W) × 122mm(H) (full extension)
- Port size: G3/8 (M14×1.5 thread optional)
- Cylinder tube material: Aluminum alloy with hard anodized surface
- Rod bearing: Oil-impregnated sintered bronze
- Seal material: NBR + PU combination
- Protection rating: IP54 (standard), IP67 optional
High-precision industrial cylinder featuring dual hardened steel rods for enhanced stability under heavy moment loads. The T-slot adjustment system allows ±5mm stroke fine-tuning without disassembly. Integrated wear indicators and grease fittings enable predictive maintenance. Requires ISO 8573-1:2010 Class 3 compressed air.
- Die casting machine ejection systems
- Automotive welding fixture positioning
- Paper roll clamping in printing presses
- Heavy-duty material transfer gates
- Plastic injection molding machine core pulls
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. For vertical installations,
use auxiliary rod supports when handling loads >500kg. Lubricate through grease nipple
every 50km of cumulative travel.
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
