Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-20S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-20S Dual-Axis Adjustable Cylinder Specifications
- Model: SIJ100X1000-20S
- Type: Dual-axis adjustable cylinder with magnetic piston
- Bore size: 100mm
- Stroke: 1000mm (adjustable via external stopper)
- Rod diameter: 25mm (both rods)
- Operating pressure: 0.05–1.0 MPa
- Max thrust: 785N @ 0.63MPa
- Cushion type: Adjustable rubber bumper (both ends)
- Mounting style: FEM-100 base with M8x1.25 mounting holes
- Operating temperature: -10℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rods
- Port size: G3/8 (standard) with NPT option
- Weight: 14.5kg (dry)
- Dimensions: 1230mm(L) × 180mm(W) × 180mm(H)
- Position detection: Built-in magnet for sensor mounting (20S suffix)
High-precision dual-rod cylinder engineered for heavy-duty alignment applications requiring parallel motion stability. Features twin chrome-plated shafts to prevent rotation under load, with anodized barrel for corrosion resistance. Includes wear-resistant polyurethane seals and adjustable stroke limiter with ±2mm fine-tuning capability.
- Precision press tool guiding systems
- Automated welding fixture positioning
- Sheet metal bending machine actuators
- Semiconductor wafer handling robots
- Heavy conveyor gate mechanisms
Installation note:
Requires minimum 0.3MPa lubrication pressure for optimal seal performance.
Align shafts within 0.1mm/m parallelism tolerance during mounting.
Allow 50mm clearance at stroke ends for cushion effectiveness.
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
