Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-40
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-40 Dual Rod Adjustable Cylinder Specifications
- Model: SIJ100X1000-40
- Type: Dual rod adjustable stroke cylinder
- Bore size: 100mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting type: MF1 (basic front flange)
- Port size: Rc1/4 (G1/4 optional)
- Piston rod diameter: 25mm (both rods)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal type: NBR seals with wear-resistant ring
- Weight: 12.8kg ±3%
- Dimensions:
- Length: 1360mm (full extension)
- Width: 152mm (including mounting flange)
- Height: 100mm (barrel diameter)
- Max theoretical thrust: 785N @ 0.63MPa
- Lubrication: Pre-lubricated (oil-free operation possible)
Heavy-duty dual rod cylinder designed for precision positioning in long-stroke applications. Features synchronized dual piston rods for enhanced moment resistance and alignment stability. The adjustable stroke mechanism allows fine-tuning through external locking nuts (40mm adjustment range included in model designation).
- Automated palletizing systems requiring precise stop positions
- Large-format CNC machine tool clamping mechanisms
- Automotive production line material transfer units
- Glass panel handling equipment with variable lengths
- Plastic injection molding machine ejector systems
- Use M10 mounting bolts (grade 8.8 or higher) for flange installation
- Maintain 0.1mm/m maximum misalignment between rod ends
- Install rod end supports when stroke exceeds 800mm
- Apply ISO VG32 hydraulic oil if manual lubrication required
- Allow 50mm clearance behind cylinder for stroke adjustment
Maintenance note:
Regularly check rod parallelism using dial indicator (max 0.2mm deviation). Replace cushion seals every 500,000 cycles in high-speed applications.
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
