Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X1000-50S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X1000-50S Twin Axis Adjustable Cylinder Specifications
- Model: SIJ100X1000-50S
- Type: Double rod adjustable stroke cylinder (ISO 15552 standard)
- Bore size: 100mm
- Stroke: 1000mm (adjustable via external stoppers)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Port size: G1/2 (NPT1/2 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: HNBR seals with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Weight: 28.5 kg (±2%)
- Dimensions: 1330mm(L) × 150mm(W) × 150mm(H)
- Mounting type: 50S series - Front flange with mounting holes
- Lubrication: Pre-lubricated (Oil-free operation possible)
Heavy-duty twin rod cylinder engineered for precision positioning in long-stroke applications. Features dual-axis guidance for enhanced moment resistance and alignment stability. The 50S mounting variant includes reinforced flange brackets for high moment load applications. Built-in magnetizable piston enables position feedback when used with magnetic sensors (sensor not included).
- Automotive welding fixture positioning systems
- Press machine ejection mechanisms
- Steel coil handling equipment
- Large-format CNC router tool changers
- Solar panel production line conveyors
Installation guidelines:
Ensure alignment tolerance ≤0.2mm/m between cylinder axis and load movement path.
For full stroke operation, maintain 20mm clearance beyond mechanical stoppers.
Lubricate guide rods weekly with ISO VG32 hydraulic oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SIJ100X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
