Airtac SIJ160 Double Rod Adjustable Cylinder SIJ160X1000-50
1. Compliant with ISO15552 (formerly ISO6431) standard cylinder specifications;
2. Piston sealing system employs dual Y-type bidirectional seals with compensation function, delivering extended service life and low dynamic friction;
3. Features corrosion-resistant chromium-plated piston rod and cross-shaped cylinder tube structure;
4. Ensures smooth and stable cylinder operation;
5. Offers multiple cylinder specifications and compatible mounting accessories for flexible customer configurations.
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ160
AirTAC SIJ160X1000-50 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ160X1000-50
- Type: Double rod adjustable stroke cylinder (ISO 15552 standard)
- Bore size: 160 mm
- Stroke: 1000 mm (adjustable via mechanical stoppers)
- Rod diameter: 50 mm (hard chrome-plated steel)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Front/rear flange (ISO 15552-MF1/MF2 compatible)
- Port size: G1/2 (ISO 1179-1 standard)
- Material: Aluminum alloy body (hard anodized) with stainless steel tie rods
- Seal type: NBR seals (oil & abrasion resistant)
- Weight: 23.8 kg (excluding mounting accessories)
- Dimensions: 1185mm(L) × 192mm(W) × 192mm(H) (stroke extended)
- Rod thread: M30×2.0 (both ends)
- Max theoretical force: 18,086N @0.63MPa
- Speed range: 50–1000 mm/s (lubricated operation)
Heavy-duty dual rod cylinder engineered for precision linear motion in industrial automation. Features reinforced rod guidance with dual bearings for moment load resistance. The adjustable stroke mechanism allows ±5mm fine-tuning via hex wrench. Corrosion-resistant construction with IP65 protection rating ensures reliable performance in harsh environments.
- Automotive welding fixture positioning systems
- Press machine tooling height adjustment
- Large-scale material handling gates
- Plastic injection molding ejector mechanisms
- Semiconductor wafer transfer systems
Installation notes:
- Requires 0.5° maximum angular misalignment compensation
- Use M12×1.25 mounting bolts (Grade 8.8 or higher)
- Pre-lubricated – relubricate every 6 months with ISO VG32 hydraulic oil
- For vertical installations, add rod end support brackets
| Property | Property Value |
|---|---|
| sku | SIJ160X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 80°C Speed Range: 30-500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | 160mm |
| Stroke | <1000mm> |
