Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X100-20STC
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Piston seal utilizes dual Y-type bidirectional sealing structure with compensation function, offering long service life and low dynamic friction;
3. Cross-shaped tube design with triple tie-rod structure ensures excellent corrosion resistance;
4. Smooth adjustable cushioning mechanism with stable operation;
5. Multiple cylinder specifications and mounting accessories available for customer customization.
Category: Adjustable Cylinders | Brand: AIRTC | Series: SIJ32
AirTAC SIJ32X100-20STC Dual Axis Adjustable Cylinder Specifications
- Model: SIJ32X100-20STC
- Type: Double rod compact cylinder with adjustable stroke
- Bore size: Ø32 mm
- Stroke: 100 mm (adjustable ±2mm)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–700 mm/s
- Port size: Rc1/8 (G1/8 optional)
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Foot-mounted with dual guide rods
- Rod diameter: Ø12 mm (chrome-plated steel)
- Body material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -10℃ to 80℃
- Weight: 2.4 kg (with mounting brackets)
- Dimensions:
- Total length: 238 mm (at mid-stroke)
- Body width: 58 mm
- Height with rods: 72 mm
- Center-to-center rod spacing: 40 mm
Precision dual-axis cylinder featuring micrometer-style stroke adjustment (±2mm) via hex wrench. The chrome-plated guide rods provide exceptional lateral load capacity (max 45N lateral force) while maintaining smooth linear motion. Integrated mounting slots allow flexible installation in multi-cylinder configurations.
- Precision alignment in semiconductor wafer handling
- Variable height positioning for robotic end effectors
- Parallel gripper systems in packaging machinery
- Precision press-fit operations in automotive assembly
- Z-axis adjustment in CNC tool changers
Operation tip:
For optimal performance with adjustable stroke, lubricate adjustment screws with ISO VG32 hydraulic oil
monthly. Maintain 0.3-0.5 MPa air pressure during stroke calibration.
- Mounting brackets: MAU32 series
- Rod end fittings: MNF12-xx series
- Position sensors: SME-8P magnetic switches
| Property | Property Value |
|---|---|
| sku | SIJ32X100-20STC |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
