This model is discontinued
AirTAC has phased out the SI series. You can still order this code here: we ship the direct replacement SAIJ32X1000-20S, with the same bore, stroke, output force, port and mounting, so it fits the same application. The SAI replacement keeps the same ISO 15552 mounting interface, bore, stroke, output force and accessories, so it drops straight into existing fixtures. It is the current-production version of this cylinder with an upgraded piston seal.
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S
The AirTAC SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S is a double-acting ISO 15552 (orig. ISO 6431) profile-barrel cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. This model is discontinued — the direct replacement is the SAIJ32X1000-20S, which matches its ISO interface, bore, stroke, force and mounting.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- StatusDiscontinued → SAIJ32X1000-20S
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S
The AirTAC SIJ32X1000-20S is a double-acting double-rod ISO 15552 adjustable-stroke cylinder. A 1000 mm nominal extend stroke is shortened on-site by up to 20 mm via an external stop screw, yielding a usable 980-1000 mm window. The 32 mm bore uses a G1/8 port, M10x1.25 rod thread, and 27 mm adjustable cushions. This SIJ model is DISCONTINUED; the direct replacement is the SAIJ32X1000-20S, matching the ISO 15552 mounting interface, bore, and force.
The SAIJ upgrade utilizes an upgraded two-piece Y-shaped piston seal for lower start-up pressure and longer life. Note the stop screw sets end position only; it is not a load lock.
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S Technical Specifications
| Model | Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S |
|---|---|
| Series | SI ISO 15552 profile cylinder (discontinued) |
| Replacement | SAIJ32X1000-20S |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max standard stroke | Up to 1000 mm |
Specifications follow the official AirTAC SI datasheet (now discontinued). The SAIJ32X1000-20S carries the same ISO 15552 ratings. Confirm against the product label before installation. Thread options: PT / G / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
The SAIJ32X1000-20S produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S
| SI | ISO 15552 profile-barrel cylinder (discontinued). |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Legacy SI-family variants: SID (double rod), SIJ (adjustable stroke) — each maps to its SAI equivalent (SID→SAID, SIJ→SAIJ). Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B).
Where the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S Is Used
End-Position Trimming on Long Pushers
Dial in the exact 980-1000 mm extend reach on a 1000 mm stroke pusher without disassembling the line to add shims.
Adjustable Transfer Stop Fences
Set the precise stop fence location for varying product lengths, using the 20 mm on-site stroke adjustment.
Long-Reach Packer Positioning
Fine-tune the extended packer blade end point in a 32 mm bore actuator to accommodate carton size variations.
Replacing the Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S with the SAIJ32X1000-20S
To replace the discontinued SIJ32X1000-20S, order the direct replacement SAIJ32X1000-20S, which preserves the G1/8 port, M10x1.25 rod, and ISO 15552 mounting. The 20 mm adjust window is ideal for fine-tuning the extend endpoint without machining. Mounting options include Basic, FA, LB, and TC brackets. The -S suffix indicates a piston magnet for legacy CS1-B/DS1-B switches. Because the stroke is 1000 mm, account for side-load and rod-bending by using external guides to prevent premature seal wear.
Replacement checklist
- ✓ Same ISO 15552 interface → SAIJ32X1000-20S
- ✓ Same bore / stroke / force
- ✓ Port/thread type (PT/G/NPT)
- ✓ Magnet (-S) for sensors?
- ✓ Mounting reused (FA/FB/CA/CB/CR/LB/TC)
Airtac SIJ32 Double Rod Adjustable Cylinder SIJ32X1000-20S FAQ
Yes, the SIJ32X1000-20S is discontinued. The direct replacement is the SAIJ32X1000-20S, offering the same ISO 15552 interface, 32 mm bore, 1000 mm stroke, 20 mm adjust window, and G1/8 port.
The external stop screw provides a 20 mm adjustment window, shortening the extend stroke from 1000 mm down to 980 mm.
