Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X100-100
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X100-100 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ63X100-100
- Type: Double rod adjustable stroke cylinder
- Bore size: Ø63 mm
- Stroke: 100 mm (adjustable)
- Secondary shaft stroke: 100 mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: Rc1/4 (NPT1/4 optional)
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting style: Basic type (no built-in mounts)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR + PU combination
- Weight: 3.8 kg ±2%
- Dimensions (L×W×H): 440mm × 85mm × 85mm (extended)
- Repeat positioning accuracy: ±0.2 mm
- Max lateral load capacity: 350 N
- ISO standard: 15552 compliant
Precision dual-axis cylinder featuring independent stroke adjustment through external locking nuts (included). The T-slot design on both rods enables easy accessory mounting for multi-position fixturing. Anti-rotation mechanism maintains parallel rod alignment under heavy side loads. Includes built-in magnet for sensor mounting.
- Precision press-fit operations in automotive assembly
- Multi-axis positioning in semiconductor handling systems
- Simultaneous clamping & lifting in CNC jigs
- Packaging line product orientation adjustment
- 3D-printed object removal systems
Installation note:
Lubricate rods with ISO VG32 hydraulic oil before initial use.
For vertical installations exceeding 45° angle, use external guide mechanisms.
Maximum allowable misalignment: 0.5° between rods.
| Property | Property Value |
|---|---|
| sku | SIJ63X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
