Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X100-50H
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X100-50H Double Axis Adjustable Cylinder Specifications
- Model: SIJ63X100-50H
- Type: Double rod compact cylinder with adjustable stroke
- Bore size: Ø63mm
- Stroke: 100mm (adjustable)
- Mounting type: H-type (swivel base with female thread)
- Piston rod diameter: Ø20mm (both sides)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Port size: Rc1/4 (G1/4 optional)
- Seal material: NBR + PU combination
- Weight: 3.8 kg ±2%
- Dimensions (L×W×H):
- Extended length: 346mm
- Retracted length: 246mm
- Body width: 96mm
- Mounting base height: 50mm
- Protection class: IP65 (dust proof & water jet resistant)
- Lubrication: Pre-lubricated (DOP-free oil)
High-precision dual-axis cylinder featuring enhanced lateral load capacity through parallel rod configuration. The hardened chromium-plated piston rods and aluminum alloy body ensure durability in high-cycle applications. Integrated magnetic sensor slots (M5x0.8 thread) allow position detection compatibility.
- Precision material handling in semiconductor FOUP/LPU transport
- Vertical lifting mechanisms for CNC machine tool changers
- Parallel gripper actuation in robotic assembly cells
- Position adjustment in automotive welding jigs
- Packaging line product orientation systems
Installation guidelines:
Ensure rod alignment within 0.2mm parallel tolerance. Use flexible couplings when connecting to guided mechanisms. For vertical mounting, install lock nuts on both adjustment screws to prevent stroke drift. Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SIJ63X100-50H |
| Adjustable Stroke | <50mm> |
| Seal Material | FKM |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
