Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-75
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X1000-75 Dual Axis Adjustable Cylinder Specifications
- Model: SIJ63X1000-75
- Type: Double rod adjustable stroke cylinder
- Bore size: 63mm
- Stroke: 1000mm (adjustable)
- Rod diameter: 20mm (both rods)
- Mounting center spacing: 75mm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushion type: Adjustable elastic cushion (both ends)
- Port size: G1/2
- Seal material: NBR (standard), optional FKM
- Protection rating: IP54
- Weight: 9.8kg ±2%
- Dimensions:
- Body length: 1255mm (including rods)
- Main body width: 75mm
- Height (mounting base): 63mm
- Overall height with brackets: 95mm
High-precision dual-axis cylinder with built-in guide mechanism, designed for applications requiring exceptional lateral stability and adjustable stroke control. Features chromium-plated piston rods with scratch-resistant treatment and anodized aluminum end caps. The dual rod configuration provides balanced thrust force (1,580N at 0.5MPa) and precise linear motion. Includes magnetic piston for position sensing compatibility.
- Precision material handling in automated assembly lines
- Vertical lift mechanisms for CNC machine tool changers
- Position-adjustable clamping systems
- Automated packaging equipment with variable product sizes
- Solar panel positioning systems
Installation note:
Ensure proper alignment of dual rods using alignment jigs during installation.
Maximum allowable lateral load: 150N. Lubricate with ISO VG32 hydraulic oil
before initial operation. Recommended re-lubrication interval: 3,000km travel distance.
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
