Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X1000-75S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X1000-75S Double Axis Adjustable Cylinder Specifications
- Model: SIJ63X1000-75S
- Bore size: Ø63 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 80℃
- Port size: Rc1/4 (G1/4 optional)
- Cushion type: Adjustable rubber bumper (both ends)
- Mounting style: Standard base + side mounting holes
- Guide rod diameter: Ø20 mm chromium-plated steel
- Repeat positioning accuracy: ±0.2 mm
- Piston speed: 50–800 mm/s
- Material: Aluminum alloy barrel (hard anodized) + stainless steel guide rods
- Seal material: NBR + PU hybrid seals
- Weight: 12.8 kg (without accessories)
- Dimensions:
- Length: 1290 mm (full extension)
- Width: 160 mm (guide rod center distance)
- Height: 98 mm (barrel outer diameter)
High-precision dual-axis guided cylinder with stroke adjustment lock nuts (75S suffix indicates stainless steel guide rods). Features integrated T-slot mounting surfaces and anti-rotation mechanism. Designed for heavy lateral load applications requiring precise linear motion alignment. Requires regular lubrication (VG32 hydraulic oil recommended).
- Automated palletizing systems
- Precision glass panel handling robots
- Automotive welding fixture positioning
- Large-format CNC router tool changers
- Semiconductor wafer transfer mechanisms
Installation note:
Use alignment jigs during mounting to ensure parallel guide rod orientation.
Maximum allowable side load: 180N at mid-stroke. Lubricate guide rods weekly
in high-cycle applications (>500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SIJ63X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | <1000mm> |
