Airtac SILF Front Locking Air Cylinder SIF40X100
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X100 Technical Details
- Model: SILF SIF40X100
- Bore size: 40mm
- Stroke: 100mm
- Operation type: Double-acting with mechanical lock
- Working pressure: 0.1–1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Locking force: 1,570N (at 0.5MPa)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR + PU combination
- Ambient temperature: -10℃ to 80℃
- Port size: M5x0.8 (standard), G1/8 optional
- Mounting type: Basic front flange (ISO 15552 compatible)
- Repeat positioning accuracy: ±0.5mm
- Weight: 2.8kg (excluding accessories)
- Dimensions: 200mm(L) × 55mm(W) × 55mm(H) (extended length)
- Protection class: IP54 (standard), IP67 optional
High-precision locking cylinder with fail-safe position retention capability, featuring dual-stage sealing system for leak prevention. The integrated mechanical lock engages automatically at stroke ends, maintaining position during power loss. Optimized for vertical/horizontal installations with anti-vibration design.
- Automated assembly line position locking
- Press machine safety interlocks
- Material handling vertical load braking
- Robotic welding fixture positioning
- Elevator emergency stop systems
Installation protocol:
Lubricate with ISO VG32 hydraulic oil before operation.
Ensure lock engagement direction aligns with load vector.
Allow 0.5-1mm play during alignment to prevent side load.
| Property | Property Value |
|---|---|
| sku | SIF40X100 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 100mm |
| Lock Position | Front Cover with Lock |
