Airtac SILF Front Locking Air Cylinder SIF40X125
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X125 Technical Details
- Model: SILF SIF40X125
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 125mm
- Operating pressure: 0.1–0.8 MPa
- Port thread: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable air cushion
- Locking force: 1,200N (at 0.5MPa)
- Material: Aluminum alloy body, hardened piston rod (Cr-Mo steel)
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 2.3kg (excluding accessories)
- Dimensions: 250mm(L) × 82mm(W) × 82mm(H) (at fully retracted position)
- Mounting: ISO 15552 standard flange options (MF1/MF2)
- Protection rating: IP67 (with wiper seal)
- Optional accessories: Magnetic switch (D-A93), locking manual override
A heavy-duty locking cylinder featuring dual safety mechanisms: mechanical position lock and pneumatic holding. The chrome-plated piston rod integrates wear-resistant guide bands for smooth operation under side load conditions. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 3).
- Press machine safety interlock systems
- Vertical load holding in automated material handling
- Position retention during power failure in assembly lines
- Robotic welding fixture clamping mechanisms
- Elevator emergency brake actuators
Installation guidelines:
Engage lock mechanism before initial operation. Maintain 0.3-1MPa air pressure during locking.
Lubricate monthly with ISO VG32 turbine oil. Avoid lateral impact forces exceeding 200N.
| Property | Property Value |
|---|---|
| sku | SIF40X125 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 125mm |
| Lock Position | Front Cover with Lock |
