Airtac SILF Front Locking Air Cylinder SIF40X250
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X250 Technical Specifications
- Model: SILF SIF40X250
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 40mm
- Stroke: 250mm
- Operating pressure: 0.1–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front flange (ISO 15552 standard), optional rear flange/bracket
- Port size: 1/4" NPT (G1/8 optional)
- Locking force: 1,500N (at 0.5 MPa)
- Lock release pressure: ≥0.3 MPa
- Piston speed: 50–800 mm/s
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to +80℃
- Weight: 1.85 kg (excluding accessories)
- Dimensions: 350mm(L) × 48mm(W) × 48mm(H) (fully retracted)
- Rod thread: M12×1.25
- Protection rating: IP54 (standard), IP67 (optional wiper upgrade)
- Service life: 5,000 km (under standard operating conditions)
High-precision locking cylinder featuring fail-safe mechanical position retention. The dual-chamber locking mechanism engages automatically at stroke ends, maintaining position without continuous air supply. Enhanced wear resistance through chrome-plated piston rod (HCP treatment) and aluminum alloy barrel with oxidation protection. Requires 5μm filtered air with ISO 8573-1:2010 class 4.4.3 cleanliness.
- Vertical lifting mechanisms requiring position hold (elevator safety brakes)
- Press machine tooling position retention during power loss
- Automated assembly line clamping fixtures
- Material handling systems with emergency stop requirements
- Plastic injection molding machine core pulls
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain ≥15mm clearance around cylinder body for heat dissipation.
Locking mechanism requires weekly manual override test for maintenance.
Maximum side load: 30N (use guided carriage for heavy side loads).
| Property | Property Value |
|---|---|
| sku | SIF40X250 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <250MM> → <250mm> |
| Lock Position | Front Cover with Lock |
