Airtac SILF Front Locking Air Cylinder SIF40X600
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Locking Cylinder SIF40X600 Technical Details
- Model: SILF SIF40X600
- Bore size: 40mm
- Stroke: 600mm
- Operating pressure: 0.1–0.8 MPa
- Locking method: Pneumatic mechanical lock (front position)
- Lock holding force: ≥1,500N
- Lock activation pressure: 0.3–0.6 MPa (independent control port)
- Cushioning type: Adjustable air cushion at both ends
- Port size: 1/8" NPT (M5 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to +80℃
- Seal material: NBR (nitrile butadiene rubber)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Mounting type: Standard MF1/MF2 flange
- Weight: 2.8kg (excluding accessories)
- Dimensions: 730mm(L) × 50mm(W) × 50mm(H)
Heavy-duty locking cylinder with fail-safe position retention capability. Features dual-chamber locking mechanism with precision ground guide rods for zero backlash. Integrated shock absorbers prevent end-stroke vibration. Requires separate 4mm pneumatic line for lock activation (0.15MPa min. for release).
- Vertical lifting systems requiring position freeze during power loss
- Automated welding fixtures with intermediate position hold
- Overhead material handling equipment safety locks
- Press machine tooling with mid-stroke pause requirements
- Robotic arm end-effector positioning locks
Installation protocol:
Maintain 0.05mm/m alignment tolerance during mounting. Lubricate guide rods monthly with ISO VG32 hydraulic oil.
Locking circuit must use filtered air (5μm filtration) separate from main pneumatic supply.
| Property | Property Value |
|---|---|
| sku | SIF40X600 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 600mm |
| Lock Position | Front Cover with Lock |
