Airtac SILF Front Locking Air Cylinder SIF40X700
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Series Front Lock Cylinder SIF40X700 Technical Specifications
- Model: SIF40X700
- Type: Double-acting with mechanical front lock
- Bore size: 40mm
- Stroke: 700mm
- Operating pressure: 0.05-1.0 MPa
- Lock holding force: 1,570N (at 0.5MPa)
- Port size: G1/8 (ISO228/1 standard)
- Cushion type: Adjustable elastic cushion
- Lock mechanism: Spring-applied brake system
- Temperature range: -10℃ to 80℃
- Piston material: Hard anodized aluminum alloy
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR + PU combination
- Protection rating: IP54 (standard), IP67 (optional)
- Weight: ~3.8kg (excluding accessories)
- Dimensions: 850mm(L) × 80mm(W) × 80mm(H)
High-precision locking cylinder featuring fail-safe mechanical braking, designed for vertical load applications requiring position retention during power loss. The dual-stage sealing system combines NBR for static seals and wear-resistant PU for dynamic components. Requires 5-40μm filtered air with ISO VG32 lubricant (optional auto-lubrication port).
- Automated welding fixture position locking
- Vertical elevator safety brakes in material handling
- Press machine intermediate stroke holding
- Solar panel tilt adjustment mechanisms
- Robotic arm overload protection systems
Installation protocol:
Mounting orientation must keep lock mechanism downward. Allow minimum 50mm
clearance for lock disengagement. Perform weekly lubrication checks during
high-cycle operations (＞5,000 cycles/day).
| Property | Property Value |
|---|---|
| sku | SIF40X700 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 700mm |
| Lock Position | Front Cover with Lock |
